Working conditions
Identify temperature, contact fluids and repeated movement.
Custom manufacturing example · 3m adhesive rubber pads for shock absorber
CUSTOM RUBBER & SILICONE MANUFACTURING
3m adhesive rubber pads for shock absorber
A custom component for your assembly.
Define the mating surfaces, dimensions and working conditions. ETOL manufactures the part to the agreed design and material.
- Factory direct
- Made to order
- Drawing & sample support
Share the part, its application and your estimated quantity.
Customize the fit, material and finish
Material & hardness
Selected for the contact, temperature and movement
Color & finish
Define the visible surfaces and intended color
Shape & dimensions
Develop holes, lips and walls around the mating parts
Mounting & fit
Match the attachment and installation method
Product Overview
Custom adhesive rubber pads can provide a cushioning interface in an assembly intended to absorb contact or shock. The rubber and adhesive need to work together: the pad should receive force through its designed contact area without that force peeling the backing away.
ETOL offers changes to size, structure, compound, hardness and color. Establish the movement that brings the mating parts together and the surface available for bonding. A pad receiving a glancing contact may experience different attachment demands from one compressed squarely.
Apply the chosen backing to a prepared surface and allow its required bond development. Observe the first contact cycles at a controlled pace, looking for sliding, an edge rolling upward or rubber pushed beyond the supporting area. Evaluate the intended cushioning function in the complete assembly. During servicing, inspect the bond as well as the exposed rubber. Correct the direction or location of contact if repeated movement displaces the pad, and fit a replacement only after residue and the underlying cause have been addressed.
- Material options
- Custom rubber compound and color, selected for the contact conditions and required geometry.
- Hardness range
- 30–90 Shore A for rubber. Assess the grade against this fit requirement: A pad receiving a glancing contact may experience different attachment demands from one compressed squarely.
- Custom profile & fit
- Establish the movement that brings the mating parts together and the surface available for bonding.
- Assembly considerations
- Correct the direction or location of contact if repeated movement displaces the pad, and fit a replacement only after residue and the underlying cause have been addressed.
- Design check
- Evaluate the intended cushioning function in the complete assembly.
Photos illustrate structure or material only. Observe the first contact cycles at a controlled pace, looking for sliding, an edge rolling upward or rubber pushed beyond the supporting area. ETOL directly manufactures custom-shaped silicone and rubber parts to your requirements.
From part requirements to production
01
Define the part
Identify key dimensions, mating surfaces and quantity
02
Review material & tooling
Agree the compound and manufacturing approach
03
Evaluate the sample
Review the fit and agreed requirements in the assembly
04
Produce & inspect
Manufacture and check against the approved requirements
Review the intended assembly
Material and structure
Consider hardness together with wall thickness and support.
Installation
Check access, mating dimensions and the fitting sequence.
Ordering this custom component
Can the shape be adjusted to my mating parts?
Yes. Show the receiving opening, contact surfaces and clearance limits. We can review the dimensions and retaining features around the intended fit.
Which details should be agreed before tooling?
Agree the critical dimensions, material, hardness, visible surfaces and sample requirements. Explain how the part is installed and which interfaces control its function.
Can a sample help define the replacement?
A sample can help explain the structure. Compare it with the assembly because wear, swelling or compression may have changed its original dimensions.
How is the quotation for this part determined?
The material, part geometry, tooling, quantity and finishing affect the quotation. Include the intended batch size and delivery destination when describing your requirements.
DISCUSS THIS COMPONENT
Describe the part you need.
Share the fit, operating conditions and quantity with our manufacturing team.
