Working conditions
Identify temperature, contact fluids and repeated movement.
Custom manufacturing example · 58mm suction cup industrial strong flat vacuum cup
CUSTOM RUBBER & SILICONE MANUFACTURING
58mm suction cup industrial strong flat vacuum cup
A custom component for your assembly.
Define the mating surfaces, dimensions and working conditions. ETOL manufactures the part to the agreed design and material.
- Factory direct
- Made to order
- Drawing & sample support
Share the part, its application and your estimated quantity.
Customize the fit, material and finish
Material & hardness
Selected for the contact, temperature and movement
Color & finish
Define the visible surfaces and intended color
Shape & dimensions
Develop holes, lips and walls around the mating parts
Mounting & fit
Match the attachment and installation method
Product Overview
A 58mm suction cup needs a suitable contact area for its flexible lip to settle against the surface. The nominal size identifies this flat cup offering, while the actual sealing footprint and attachment geometry need to suit the intended installation. ETOL can customize dimensions, colors and molded details, with hardness options from 30 to 90 Shore A.
Check the available surface beyond its general appearance. A joint line, scratch, printed ridge or local curve can cross the cup perimeter and interrupt contact. Place the cup where the whole lip has continuous support, and keep the surface clean before fitting. A larger nominal diameter cannot compensate for an unsuitable patch beneath one section of the edge.
Evaluate the complete attachment under its intended force direction and duration. No load capacity follows from the 58 mm label alone. Inspect the fitted cup for an unevenly lifted rim and make sure the connected part does not pull it sideways. During repositioning, release the suction first so the lip is not dragged across the surface under tension. Renew a cup with a damaged sealing edge.
- Material options
- Rubber compound options, customized alongside the profile and contact conditions.
- Hardness selection
- Solid rubber options: 30–90 Shore A. A 58mm suction cup needs a suitable contact area for its flexible lip to settle against the surface.
- Custom geometry
- During repositioning, release the suction first so the lip is not dragged across the surface under tension.
- Fit evaluation
- Evaluate the complete attachment under its intended force direction and duration.
- Color & OEM
- Custom colors; OEM markings outside the suction contact face.
Photos illustrate structure or material appearance only. A 58mm suction cup needs a suitable contact area for its flexible lip to settle against the surface. ETOL directly manufactures custom-shaped silicone and rubber parts to your requirements.
From part requirements to production
01
Define the part
Identify key dimensions, mating surfaces and quantity
02
Review material & tooling
Agree the compound and manufacturing approach
03
Evaluate the sample
Review the fit and agreed requirements in the assembly
04
Produce & inspect
Manufacture and check against the approved requirements
Review the intended assembly
Material and structure
Consider hardness together with wall thickness and support.
Installation
Check access, mating dimensions and the fitting sequence.
Ordering this custom component
Can the shape be adjusted to my mating parts?
Yes. Show the receiving opening, contact surfaces and clearance limits. We can review the dimensions and retaining features around the intended fit.
Which details should be agreed before tooling?
Agree the critical dimensions, material, hardness, visible surfaces and sample requirements. Explain how the part is installed and which interfaces control its function.
Can a sample help define the replacement?
A sample can help explain the structure. Compare it with the assembly because wear, swelling or compression may have changed its original dimensions.
How is the quotation for this part determined?
The material, part geometry, tooling, quantity and finishing affect the quotation. Include the intended batch size and delivery destination when describing your requirements.
DISCUSS THIS COMPONENT
Describe the part you need.
Share the fit, operating conditions and quantity with our manufacturing team.
