Custom manufacturing example · Custom rubber anti vibration bumper/small rubber damper
CUSTOM RUBBER & SILICONE MANUFACTURING
Custom rubber anti vibration bumper/small rubber damper
A custom component for your assembly.
Define the mating surfaces, dimensions and working conditions. ETOL manufactures the part to the agreed design and material.
- Factory direct
- Made to order
- Drawing & sample support
Share the part, its application and your estimated quantity.
Customize the fit, material and finish
Material & hardness
Selected for the contact, temperature and movement
Color & finish
Define the visible surfaces and intended color
Shape & dimensions
Develop holes, lips and walls around the mating parts
Mounting & fit
Match the attachment and installation method
Product Overview
A small rubber damper should present its working face where the adjacent component is intended to contact it. Custom molded dimensions can follow a compact installation, while the compound suits the operating environment. The attachment must keep that contact position consistent during normal use.
Check the face alignment and surrounding clearance through the complete movement. An edge-loaded bumper may wear differently from one supported across its intended area. The body should have enough space for the deformation established by the design without another hard surface being reached first.
Fit through the specified retention method and assess the complete mechanism under normal conditions. The loose rubber part does not define a particular anti-vibration performance. During maintenance, inspect wear patterns and the attachment for damage or movement. Replace with the matching profile and compound rather than making the buffer taller to conceal a changed contact position. Preserve the original working face location and check the mating geometry where uneven wear recurs.
- Material options
- Rubber compound options, customized alongside the profile and contact conditions.
- Hardness selection
- Solid rubber options: 30–90 Shore A. Fit through the specified retention method and assess the complete mechanism under normal conditions.
- Custom geometry
- Check the face alignment and surrounding clearance through the complete movement.
- Fit evaluation
- The attachment must keep that contact position consistent during normal use.
- Color & OEM
- Custom colors; part identification clear of mounting seats and loaded faces.
Photos illustrate structure or material appearance only. A small rubber damper should present its working face where the adjacent component is intended to contact it. ETOL directly manufactures custom-shaped silicone and rubber parts to your requirements.
From part requirements to production
01
Define the part
Identify key dimensions, mating surfaces and quantity
02
Review material & tooling
Agree the compound and manufacturing approach
03
Evaluate the sample
Review the fit and agreed requirements in the assembly
04
Produce & inspect
Manufacture and check against the approved requirements
Review the intended assembly
Material and structure
Consider hardness together with wall thickness and support.
Installation
Check access, mating dimensions and the fitting sequence.
Ordering this custom component
Can the shape be adjusted to my mating parts?
Yes. Show the receiving opening, contact surfaces and clearance limits. We can review the dimensions and retaining features around the intended fit.
Which details should be agreed before tooling?
Agree the critical dimensions, material, hardness, visible surfaces and sample requirements. Explain how the part is installed and which interfaces control its function.
Can a sample help define the replacement?
A sample can help explain the structure. Compare it with the assembly because wear, swelling or compression may have changed its original dimensions.
How is the quotation for this part determined?
The material, part geometry, tooling, quantity and finishing affect the quotation. Include the intended batch size and delivery destination when describing your requirements.
