Custom manufacturing example · High quality rubber seal gasket/round rubber washer with grooves
CUSTOM RUBBER & SILICONE MANUFACTURING
High quality rubber seal gasket/round rubber washer with grooves
A custom component for your assembly.
Define the mating surfaces, dimensions and working conditions. ETOL manufactures the part to the agreed design and material.
- Factory direct
- Made to order
- Drawing & sample support
Share the part, its application and your estimated quantity.
Customize the fit, material and finish
Material & hardness
Selected for the contact, temperature and movement
Color & finish
Define the visible surfaces and intended color
Shape & dimensions
Develop holes, lips and walls around the mating parts
Mounting & fit
Match the attachment and installation method
Product Overview
A round rubber washer with grooves includes recessed features that must be interpreted as part of the working profile. A groove may correspond to a locating or contact feature in the receiving assembly; it should not be assumed to serve as a fluid channel simply because it forms a recess in the rubber.
Establish which side faces each mating component. The groove's position relative to the bore and outer edge can make orientation important even when the loose washer appears symmetrical from a distance. Compare the whole cross section with the intended seat, including the lands beside the groove that will make contact.
During fitting, ensure those lands reach their mating faces without the groove being flattened by an incompatible projection. Keep residue out of the recess so its geometry remains available for the intended function. For replacement, inspect the old groove under good visibility and distinguish trapped deposits from damaged rubber. The custom material and dimensions should match the actual joint duty. A flat washer with the same diameter cannot reproduce the recessed profile or its locating relationship.
- Material options
- Rubber. Custom formulation and color for the intended contact conditions.
- Hardness selection
- Rubber: 30–90 Shore A. Choose the rubber response with the groove correctly oriented to the bore; a recessed face can change local compression despite a symmetric outline.
- Custom dimensions
- A flat washer with the same diameter cannot reproduce the recessed profile or its locating relationship.
- Fit & assembly
- Compare the whole cross section with the intended seat, including the lands beside the groove that will make contact.
- Use & inspection
- For replacement, inspect the old groove under good visibility and distinguish trapped deposits from damaged rubber.
Photos illustrate structure or material only. The groove's position relative to the bore and outer edge can make orientation important even when the loose washer appears symmetrical from a distance. ETOL directly manufactures custom-shaped silicone and rubber parts to your requirements.
