Custom manufacturing example · Molded electronic devices rubber silicone mount/small damper
CUSTOM RUBBER & SILICONE MANUFACTURING
Molded electronic devices rubber silicone mount/small damper
A custom component for your assembly.
Define the mating surfaces, dimensions and working conditions. ETOL manufactures the part to the agreed design and material.
- Factory direct
- Made to order
- Drawing & sample support
Share the part, its application and your estimated quantity.
Customize the fit, material and finish
Material & hardness
Selected for the contact, temperature and movement
Color & finish
Define the visible surfaces and intended color
Shape & dimensions
Develop holes, lips and walls around the mating parts
Mounting & fit
Match the attachment and installation method
Product Overview
A rubber silicone mount for an electronic device should fit the available enclosure space and the supported component. The molded dimensions need to establish the intended height and attachment relationship. Material selection should suit the local temperature and contact conditions inside the equipment.
Check nearby circuit boards, covers, connectors, and fasteners for clearance. A mount may fit before the enclosure closes yet become restricted by the final housing position. The supported component should remain aligned while the rubber retains the movement required by the design.
Install using the device's specified arrangement and evaluate the complete assembly under normal operation. Avoid treating a standard-looking body as proof of a particular damping level. During maintenance, inspect the attachment and flexible region for damage or persistent displacement. Recheck clearance after replacing neighboring components. Match the required profile and compound in the replacement so that the original enclosure relationship is preserved instead of altered by a different installed height.
- Material options
- Custom silicone compound; formulation and geometry developed together.
- Hardness selection
- Silicone options: 20–80 Shore A. Material selection should suit the local temperature and contact conditions inside the equipment.
- Custom geometry
- Check nearby circuit boards, covers, connectors, and fasteners for clearance.
- Fit evaluation
- Install using the device's specified arrangement and evaluate the complete assembly under normal operation.
- Color & OEM
- Custom colors; identification clear of connectors and removal features.
Photos illustrate structure or material appearance only. The supported component should remain aligned while the rubber retains the movement required by the design. ETOL directly manufactures custom-shaped silicone and rubber parts to your requirements.
From part requirements to production
01
Define the part
Identify key dimensions, mating surfaces and quantity
02
Review material & tooling
Agree the compound and manufacturing approach
03
Evaluate the sample
Review the fit and agreed requirements in the assembly
04
Produce & inspect
Manufacture and check against the approved requirements
Review the intended assembly
Material and structure
Consider hardness together with wall thickness and support.
Installation
Check access, mating dimensions and the fitting sequence.
Ordering this custom component
Can the shape be adjusted to my mating parts?
Yes. Show the receiving opening, contact surfaces and clearance limits. We can review the dimensions and retaining features around the intended fit.
Which details should be agreed before tooling?
Agree the critical dimensions, material, hardness, visible surfaces and sample requirements. Explain how the part is installed and which interfaces control its function.
Can a sample help define the replacement?
A sample can help explain the structure. Compare it with the assembly because wear, swelling or compression may have changed its original dimensions.
How is the quotation for this part determined?
The material, part geometry, tooling, quantity and finishing affect the quotation. Include the intended batch size and delivery destination when describing your requirements.
