Custom manufacturing example · Rubber vibration damper plate with high performance
CUSTOM RUBBER & SILICONE MANUFACTURING
Rubber vibration damper plate with high performance
A custom component for your assembly.
Define the mating surfaces, dimensions and working conditions. ETOL manufactures the part to the agreed design and material.
- Factory direct
- Made to order
- Drawing & sample support
Share the part, its application and your estimated quantity.
Customize the fit, material and finish
Material & hardness
Selected for the contact, temperature and movement
Color & finish
Define the visible surfaces and intended color
Shape & dimensions
Develop holes, lips and walls around the mating parts
Mounting & fit
Match the attachment and installation method
Product Overview
A rubber vibration damper plate provides a broad interface that can be shaped around an equipment support. Its working behavior depends on where the load enters the plate and how the opposite face is supported. A large outline does not guarantee even loading if the base contacts only a few narrow regions.
Define the footprint, thickness, attachment features, and room for deformation. Check the supported mass and movement direction, including changes during startup or stopping where relevant. The rubber compound should suit the local temperature and substances present around the mounting area.
Install the plate flat without forcing it across a misaligned support. Inspect nearby hardware for rigid contact that could transfer force around the rubber. Cables, pipes, or other connections should also be considered when assessing the complete equipment response. Evaluate vibration using the actual installed arrangement rather than the plate's material alone.
During maintenance, compare compression across the plate and inspect edges near fasteners for tears. Uneven deformation can reveal a load distribution or base alignment issue. If the same area repeatedly deteriorates, correct the surrounding contact before fitting another plate. The replacement should begin with the intended support and clearance so its flexible region is not used to compensate for a structural mismatch.
- Material options
- Rubber compound options, customized alongside the profile and contact conditions.
- Hardness selection
- Solid rubber options: 30–90 Shore A. Uneven deformation can reveal a load distribution or base alignment issue.
- Custom geometry
- Define the footprint, thickness, attachment features, and room for deformation.
- Fit evaluation
- Evaluate vibration using the actual installed arrangement rather than the plate's material alone.
- Color & OEM
- Custom colors; part identification clear of mounting seats and loaded faces.
Photos illustrate structure or material appearance only. A Rubber vibration damper plate provides a broad interface that can be shaped around an equipment support. ETOL directly manufactures custom-shaped silicone and rubber parts to your requirements.
From part requirements to production
01
Define the part
Identify key dimensions, mating surfaces and quantity
02
Review material & tooling
Agree the compound and manufacturing approach
03
Evaluate the sample
Review the fit and agreed requirements in the assembly
04
Produce & inspect
Manufacture and check against the approved requirements
Review the intended assembly
Material and structure
Consider hardness together with wall thickness and support.
Installation
Check access, mating dimensions and the fitting sequence.
Ordering this custom component
Can the shape be adjusted to my mating parts?
Yes. Show the receiving opening, contact surfaces and clearance limits. We can review the dimensions and retaining features around the intended fit.
Which details should be agreed before tooling?
Agree the critical dimensions, material, hardness, visible surfaces and sample requirements. Explain how the part is installed and which interfaces control its function.
Can a sample help define the replacement?
A sample can help explain the structure. Compare it with the assembly because wear, swelling or compression may have changed its original dimensions.
How is the quotation for this part determined?
The material, part geometry, tooling, quantity and finishing affect the quotation. Include the intended batch size and delivery destination when describing your requirements.
