Custom flexible silicone rubber seal/rubber gasket with grooves

A custom component for your assembly.

Define the mating surfaces, dimensions and working conditions. ETOL manufactures the part to the agreed design and material.

Factory direct
Made to order
Drawing & sample support

Share the part, its application and your estimated quantity.

Customize the fit, material and finish

Vulcanization workshop illustration with green molding presses and blue collection bins

Material & hardness

Selected for the contact, temperature and movement

Color & finish

Define the visible surfaces and intended color

Shape & dimensions

Develop holes, lips and walls around the mating parts

Mounting & fit

Match the attachment and installation method

Product Overview

A rubber gasket with grooves should be oriented so its molded features meet the intended mating surfaces. Grooves can affect how the part locates or deforms, depending on the selected design, so their position should not be treated as interchangeable with a flat face. Match the silicone seal profile to the full joint rather than selecting from its outside dimensions alone.

Check the groove depth, adjacent sections, and available compression. Keep narrow regions supported where the faces close. Select the formulation for the actual medium, temperature, and cleaning process, including any residue that may collect in recessed features.

Install in the specified orientation on clean surfaces without stretching the profile into alignment. Inspect the grooved regions for trapped particles before closure. During service, look for a folded ridge or local tear that corresponds to an incorrectly seated feature. Correct alignment or the mating surface before replacement instead of flattening or trimming molded details that belong to the intended contact geometry.

Material options: Silicone. Custom formulation and color for the intended contact conditions.
Hardness selection: Silicone: 20–80 Shore A. Grooves can affect how the part locates or deforms, depending on the selected design, so their position should not be treated as interchangeable with a flat face.
Custom dimensions: Match the silicone seal profile to the full joint rather than selecting from its outside dimensions alone.
Fit & assembly: Install in the specified orientation on clean surfaces without stretching the profile into alignment.
Use & inspection: Select the formulation for the actual medium, temperature, and cleaning process, including any residue that may collect in recessed features.

Photos illustrate structure or material only. A rubber gasket with grooves should be oriented so its molded features meet the intended mating surfaces. ETOL directly manufactures custom-shaped silicone and rubber parts to your requirements.

Choosing a material or hardness? Explore the selection guide →

From part requirements to production

Define the part

Identify key dimensions, mating surfaces and quantity

Review material & tooling

Agree the compound and manufacturing approach

Evaluate the sample

Review the fit and agreed requirements in the assembly

Produce & inspect

Manufacture and check against the approved requirements

Review the intended assembly

Working conditions

Identify temperature, contact fluids and repeated movement.

Material and structure

Consider hardness together with wall thickness and support.

Installation

Check access, mating dimensions and the fitting sequence.

Ordering this custom component

Can the shape be adjusted to my mating parts?

Yes. Show the receiving opening, contact surfaces and clearance limits. We can review the dimensions and retaining features around the intended fit.

Which details should be agreed before tooling?

Agree the critical dimensions, material, hardness, visible surfaces and sample requirements. Explain how the part is installed and which interfaces control its function.

Can a sample help define the replacement?

A sample can help explain the structure. Compare it with the assembly because wear, swelling or compression may have changed its original dimensions.

How is the quotation for this part determined?

The material, part geometry, tooling, quantity and finishing affect the quotation. Include the intended batch size and delivery destination when describing your requirements.
