Working conditions
Identify temperature, contact fluids and repeated movement.
Custom manufacturing example · Black rubber shock-absorber/rubber damper with metal parts
CUSTOM RUBBER & SILICONE MANUFACTURING
Black rubber shock-absorber/rubber damper with metal parts
A custom component for your assembly.
Define the mating surfaces, dimensions and working conditions. ETOL manufactures the part to the agreed design and material.
- Factory direct
- Made to order
- Drawing & sample support
Share the part, its application and your estimated quantity.
Customize the fit, material and finish
Material & hardness
Selected for the contact, temperature and movement
Color & finish
Define the visible surfaces and intended color
Shape & dimensions
Develop holes, lips and walls around the mating parts
Mounting & fit
Match the attachment and installation method
Product Overview
A black rubber damper with metal parts should be identified by its complete construction, not by color alone. The rigid connection details and molded body dimensions need to match the intended equipment position. The compound should suit the actual load, movement, and environment.
Compare the metal attachment geometry with the receiving component before fitting. Differences in engagement or support height can change the installed relationship even where two rubber bodies look similar. The working section also needs clearance from adjacent hardware throughout its intended movement.
Use the equipment's specified installation method and assess the complete assembly under normal operation. During maintenance, inspect the metal connection and nearby rubber transitions for loosening, cuts, or persistent displacement. Keep visually similar variants separated if their compounds or connection details differ. Use a replacement with the required material and full profile so that the original rigid and flexible interfaces are preserved rather than selecting by the visible black outline alone.
- Material options
- Custom rubber compound and color, selected for the contact conditions and required geometry.
- Hardness range
- 30–90 Shore A for rubber. Assess the grade against this fit requirement: The compound should suit the actual load, movement, and environment.
- Custom profile & fit
- Compare the metal attachment geometry with the receiving component before fitting.
- Assembly considerations
- Differences in engagement or support height can change the installed relationship even where two rubber bodies look similar.
- Design check
- Use the equipment's specified installation method and assess the complete assembly under normal operation.
Photos illustrate structure or material only. Differences in engagement or support height can change the installed relationship even where two rubber bodies look similar. ETOL directly manufactures custom-shaped silicone and rubber parts to your requirements.
From part requirements to production
01
Define the part
Identify key dimensions, mating surfaces and quantity
02
Review material & tooling
Agree the compound and manufacturing approach
03
Evaluate the sample
Review the fit and agreed requirements in the assembly
04
Produce & inspect
Manufacture and check against the approved requirements
Review the intended assembly
Material and structure
Consider hardness together with wall thickness and support.
Installation
Check access, mating dimensions and the fitting sequence.
Ordering this custom component
Can the shape be adjusted to my mating parts?
Yes. Show the receiving opening, contact surfaces and clearance limits. We can review the dimensions and retaining features around the intended fit.
Which details should be agreed before tooling?
Agree the critical dimensions, material, hardness, visible surfaces and sample requirements. Explain how the part is installed and which interfaces control its function.
Can a sample help define the replacement?
A sample can help explain the structure. Compare it with the assembly because wear, swelling or compression may have changed its original dimensions.
How is the quotation for this part determined?
The material, part geometry, tooling, quantity and finishing affect the quotation. Include the intended batch size and delivery destination when describing your requirements.
DISCUSS THIS COMPONENT
Describe the part you need.
Share the fit, operating conditions and quantity with our manufacturing team.
