Rubber Seals, O-Rings & Gaskets
Rubber seals and gaskets sit between mating surfaces to help close a joint. O-rings fit circular sealing paths, while flat or molded gaskets follow covers, flanges and enclosure edges. These parts are used in equipment housings and other assemblies with defined sealing interfaces. ETOL manufactures custom rubber gaskets and silicone seals to your joint geometry and material requirements.
Need a different shape or fit?
Develop the dimensions, material and attachment features around your assembly.
Send Your Drawing
Gasket profiles, O-ring sizes and sealing fit
How does an O-ring differ from a flat gasket?
An O-ring is a continuous ring with a defined cross-section, commonly installed in a matching groove. A flat gasket follows a wider joint face and may include bolt holes or internal openings. Choose the form around the available sealing space and compression arrangement.
How do I measure an O-ring for a size comparison?
Identify its inside diameter and cross-section, then compare those dimensions with the groove and mating parts. A used ring may have stretched, swollen or flattened. Treat its measurements as a starting point and use the intended joint dimensions to define a replacement.
Which details matter when choosing rubber gasket material?
Consider the substances touching the gasket, operating temperature and how long it stays compressed. The flange condition and closing force also affect the choice. A material name or hardness value alone does not establish whether a finished joint will seal.
Why can a soft gasket still leak?
A soft material cannot close a gap where the section never makes contact. Check the gasket thickness, corners, flange flatness and compression around the entire joint. Uneven fastening or a displaced section can leave a leak path even when the rubber feels soft.
Can a rubber washer replace a sealing gasket?
Only when the washer's shape, material and compressed contact suit the joint. Some washers mainly cushion or space a fastener rather than form a seal. Review the inside opening, outside contact area and fastening arrangement before assigning it a sealing function.
Does ETOL manufacture custom gaskets and seals?
Yes. ETOL is a custom rubber gasket manufacturer. Our gasket manufacturing work starts with the joint outline, thickness, closing force and material requirements. Custom gaskets and seals may use rubber or silicone, with molded lips, locating features or flat contact faces chosen around the mating assembly.
Which details are needed for window gaskets, door seals and pipe gaskets?
Rubber window gaskets need the glass or panel thickness and the receiving frame profile. Custom door seals must follow the closing gap and corner arrangement. Custom made rubber pipe gaskets need the flange outline, bolt positions and compressed sealing space. The intended exposure and joint dimensions determine the compound and profile for each design.
Can you supply custom O-rings and rubber washers for production orders?
ETOL supplies custom O-rings and rubber washers made to the specified design. An O-ring needs its inside diameter, cross-section and material; a washer needs its inside and outside diameters, thickness and contact function. For wholesale quantities, identify the number of each size and the packing requirements so distinct versions remain separated through delivery.
